Product Features
Description:
Brief Introduction:
Rack Mount Distribution Frames is ranging from 12 ports to 48 ports. It is suitable for the use in telecommunication network, central office optical cable system and premise fiber network.
Specification:
Rack Mount Distribution Frames is ranging from 12 ports to 48 ports. It is suitable for the use in telecommunication network, central office optical cable system and premise fiber network. One cabinet design provides OSP cable fibers and pigtail splicing, patch cords termination and storage. Each Terminal Box is fully loaded with panels, adaptors, splices trays and accessories and is ready for installation.
• Applicable in the branch connection of fiber termination. working as distribution box
• 19’’standard structure, rack mounted
• available for the installation of FC,SC,ST,LC adaptors
• Applicable in the branch connection of fiber termination. working as distribution box
• 19’’standard structure, rack mounted
• available for the installation of FC,SC,ST,LC adaptors
Ordering Info
|
Type |
Dimension(mm) |
Max capacity cores |
Remark |
|
FR-SC12 |
480*250*1U |
12 |
We choose high quality
material of cold rolled steel
sheet and good electrostatic
spraying.The fiber adaptors
and pigtails are optional and
available for FC,ST,SC,LC |
|
FR-SC24 |
480*250*1U |
24 |
|
FR-SC48 |
480*250*2U |
48 |
|
FR-FC12 |
480*250*1U |
12 |
|
FR-FC24 |
480*250*1U |
24 |
|
FR-FC48 |
480*250*2U |
48 |
|
FR-ST12 |
480*250*1U |
24 |
|
FR-ST24 |
480*250*1U |
24 |
