Product Features

Description:

Brief Introduction:

With this function, it test whether there is live single in the tested fiber and shows the results before sending pulse. It can effectively protect test instrument and communication equipment.

Complete software support
Printing mode (single trace line in one page or multi-trace lines in one page)
Batches modify and batches printing
Waveform difference comparison
Multiple traces and traces difference show in one window


Specification:
•  Added function of 650nm visible light source
•  Quick start :< 5 seconds
•  Unique hotkey design: Key operation integrated hot key function , quick positioning and event analysis
•  USB/RS-232 data interface
•  1000 traces storage
•  Up to 8 hours measurement with built-in NiMH rechargeable battery.
•  Multiple languages:
•  CN/EN/DE/FR/RU/ES/PT/KR/VN
•  Dust-shock proof (2m drop test)
•  CE, FCC, FDA certificates



Type

A

B

Dynamic Range(dB)

32/32

30/28

Fiber  Type

SM

Wavelength(nm) (±20nm)

1310/1550

Display Type

Colorful

Emitter Type

LD

Connector  Type

FC/PC(Interchangeable SC, ST)

Measurement  Time

15ss、1min、2min、3min

Attenuation zone

12m

18m

Event dead zone

2.5m

5m

Distance Test Accuracy

±(1 m + 5×10-5×distance + sampling space)

Attenuation Test Accuracy

±0.05 dB/ dB

Reflection Test Accuracy

±4 dB

Data Storage

1000

Data Transmission

RS-232/USB

VFL Output Power(dBm)

 ≥-3

VFL Test Distance (km)

5

Power Supply

NiMH chargeable battery/ AC adapter

Operating Temperature

0℃ ~ 50℃

Storage Temperature

-20℃ ~ 70℃

Relative Humidity

0~95%(non-condensing)
